For Optimal Use:
1. The inverter does NOT apply to high power electric devices such as electric heaters, curling irons, etc.
2. This is a modified sine wave series inverter, NOT applicable for air conditioners, refrigerators and microwave ovens, please choose our pure sine wave inverters.
3. If the output power of the inverter is HIGHER than 150W, we strongly recommend you using the Crocodile Clips to a battery (clips are included) but not the cigarette lighter, because your car cigarette lighter might not afford power over 150W.
4. When using reactive load appliances, the start power will be 2-5 times of continuous output / rated output power, but must be lower than start power of the inverter.
5. 3000W is the peak output power of this inverter. The continuous output / rated output power is about 45%~60% of the peak power.
Â
Package Included:
1 x Power Inverter
1 x Cigarette lighter plug
2 x Crimper
4 x Fuse(40A)
1 x User Manual
DC Input Voltage | 12V |
Output Waveform | Modified Sine Wave |
Output Continuous Power | 1500 Watt |
Surge Power | 3000 Watts (< 1 second) |
DC Input Voltage | 12V |
AC Output Voltage | 110V ±5% 60Hz |
USB Charge Port | 5V, 3.1A |
Sockets | 2 X AC Type B outlets, 2 X 3.1A USB ports |
Input Voltage Range | DC 11V - 15V |
Input Low-Voltage Alarm | DC 10V ±0.5V |
Under-Voltage Cut-Off Voltage | DC 9V ±0.5V |
Input Over-Voltage Cut-Off Voltage | DC 15.5V |
Thermal-Shutdown | > 167°F (> 75℃) |
Efficiency | > 88% |
No-load Current (Stand-by) | < 1.2 Amps |
Protection | Overload / Short Circuit / Over heat / Reverse Polarity / Under/Over Voltage |
THD | < 5% (Linear load) |
Certificate | FCC |
Built-in Cooling Fan | Yes |
Weight | 1.7kg / 3.75 pounds |
Dimensions | 26.5 x 12 x 7 cm / 10.4 x 4.7 x 2.8 inches |
Battery Cable | 20 inch / 510 mm |
